9905-764 WOODWARD

Brand:  WoodWard

Model number:9905-764

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.85kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

9905-764   WOODWARD

INQUIRE NOW

Products Name: 9905-764 WOODWARD

PRODUCT DESCRIPTION

Be prepared to make an emergency shutdown when starting the engine, turbine, or other type of prime mover, to protect against runaway or overspeed with possible personal injury, loss of life, or property damage.

Benefits:

Preset rated speed.

 If a signal generator is not used, set the RATED SPEED potentiometer at

minimum (fully counterclockwise).

 If a signal generator is used set the signal for the frequency of the speed

sensor at rated speed, and connect it to terminals 7 and 8. (The rated speed

frequency in Hz equals the rated engine speed in RPM times the number of

teeth on the speed sensing gear, times the ratio of engine speed to speedsensing-gear speed, divided by 60.) Put the Close For Rated contact in

rated (closed) position. Set the speed trim potentiometer (if used) to midposition. Connect a dc analog voltmeter to terminals 9 (+) and 10 (–) to read

actuator voltage.

 If the actuator voltage is at minimum (about 0 volts) slowly turn the RATED

SPEED potentiometer clockwise (counterclockwise for reverse acting

controls) until the voltage just begins to move toward maximum.

 If the actuator voltage is at maximum, slowly turn the RATED SPEED

potentiometer counterclockwise (clockwise for reverse-acting controls) until

the voltage just begins to move toward minimum.

 Continue to very slowly adjust the RATED SPEED potentiometer in the

appropriate direction, trying to stop the actuator voltage between the

minimum and maximum voltages. Because it is not possible to stop the

motion, cease adjusting when the voltage changes very slowly. The RATED

SPEED potentiometer is now set very close to the desired speed. A slight

adjustment when the engine is running will achieve the exact speed.


9905-764   WOODWARD

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
